Məhsul tələbi
Network Adapter |
|
| 10/100 Mbit/s | 1 |
| Type 10/100 Mbit/s | RJ-45 |
Network Technology |
|
| Protocol | BootP, HTTP, TFTP, TCP, UDP, DHCP |
Industrial Protocols |
|
| CAN Port | 2 |
| CAN Version | ISO-11898-2, CAN 2.0A, CAN 2.0B, CAN FD |
Connectors / Cables |
|
| Connectors | RJ45, 2xDB9 CAN |
System Power Input |
|
| Input Voltage DC | 10~30 V |
| Power Consumption | 1.2 W |
| Current | 0.05 A |
Operating Conditions |
|
| Temperature | -25~75 °C |
| Humidity | 10~90 % |
Storage Conditions |
|
| Temperature Range | -30~80 °C |
| Humidity | 10~90 % |
Construction |
|
| Construction Chassis | Metal Chassis |
| Mounting Configuration | DIN-Rail mount |
Dimensions and weight |
|
| Width | 122 mm |
| Height | 28 mm |
| Depth | 160 mm |
