Main |
|
| Charging station type | Free-standing/mobile |
| Installation side connection model | Single phase |
| Charging mode | Mode 2 |
| Number of charging units | 1 |
| Max. power per charging point | 3.6 kW |
| Connectors | Type 2 |
Connection to the vehicle |
|
| Connection to the vehicle | Charging plug |
| Type of socket | Type 2 |
| Max power | 3.6 kW |
| Maximum current | 10 A |
| E-Mobil side connection model | AC single phase |
| Length of the fixed connection cable | 6 m |
| Cable type | Straight |
Complementary |
|
| Access control | No |
| Earth leakage protection | AC 30mA, DC 6mA |
| With load management | Yes |
| With circuit breaker | Yes |
| With temperature sensor | Yes |
Construction |
|
| Construction Chassis | Plastic Chassis |
| Protection Level of Chassis | IP67 |
| Color | black |
System Power Input |
|
| Input Voltage AC | 110~240 V |
Standards and Certifications |
|
| Power Automation | IEC 61851-1 |
