MDR-20-24

MDR-20-24

Mean Well
Qiymət istəyə görə
AC Input 85-264VAC, 120-370VAC Industrial Power Supply , Output 24VDC/1A, DIN-Rail Mounting

Power Supply
Type of Power Supply Direct current
Output Voltage DC 24 V
Rated current 1 A
Output Power 24 W
Input Voltage AC 85~264 V
Input Voltage DC 120~370 V

Construction
Mounting Configuration DIN-Rail mount

Connectors / Cables
Connectors Screw Terminal

Operating Conditions
Temperature -20~70 °C
Humidity 20~90 %

Storage Conditions
Temperature Range -40~85 °C

Dimensions and weight
Width 23 mm
Height 90 mm
Depth 100 mm
