Network Adapter |
| Total Ethernet |
2 |
| 10/100 Mbit/s |
2 |
| Type 10/100 Mbit/s |
1xSC, 1xRJ-45 |
Cooling |
| Type |
Fanless |
System Power Input |
| Input Voltage DC |
18~36 V |
| Power Consumption |
5 W |
Operating Conditions |
| Temperature |
-40~85 °C |
| Humidity |
0~95 % |
Storage Conditions |
| Temperature Range |
-40~80 °C |
Construction |
| Construction Chassis |
Heavy-Duty Steel Chassis |
| Mounting Configuration |
Wall, DIN-Rail mount |
| Protection Level of Chassis |
IP40 |
Dimensions and weight |
| Width |
58 mm |
| Height |
109 mm |
| Depth |
94 mm |
Standards and Certifications |
| Certifications |
CE/FCC |
| Safety |
UL 60950-1, CSA |
| EMS |
EN 61000-6-2, EN 61000-6-4 |
| EMI |
EN 61000-6-4, EN 55022 Class A, FCC Part 15 Subpart B Class A |
| Power Automation |
IEC 61850-3, IEEE 1613 |
