Power Supply |
|
| Type of Power Supply | Direct current |
| Output Voltage DC | 12~12 V |
| Output Power | 120 W |
| Type of input voltage | AC |
| Input Voltage AC | 88~264 V |
| Input Voltage DC | 124~370 V |
Construction |
|
| Mounting Configuration | DIN-Rail mount |
Connectors / Cables |
|
| Connectors | Screw Terminal |
Operating Conditions |
|
| Temperature | -25~70 °C |
| Humidity | 20~90 % |
Storage Conditions |
|
| Temperature Range | -40~85 °C |
Dimensions and weight |
|
| Width | 40 mm |
| Height | 126 mm |
| Depth | 114 mm |
